iPhone 13 Pro Max - Black - Pulled Diagnostic Screen For Fast, Reliable Repairs
This genuine oled display and digitizer assembly is pulled from an original device and bench-tested, giving you a dependable iPhone 13 Pro Max - Black - Pulled Diagnostic Screen for repeatable results and quick turnaround. You get authentic color accuracy, smooth 120 hz motion, and precise touch response that match factory behavior, ideal for high-volume repair benches and refurbishment lines.
This unit is ready for direct fit on iPhone 13 Pro Max and keeps the black front glass and bezel for a clean, oem-matched look. The assembly arrives fully inspected for no-touch faults, uniform brightness, stable refresh behavior, and clean polarizer alignment, so you can install, program true tone, seal, and ship with confidence.
Full Technical Data For iPhone 13 Pro Max Display
Display type is super retina xdr oled with promotion 120 hz adaptive refresh, 6.7 inch diagonal active area, and 2778 × 1284 resolution at458 ppi. Typical max brightness is up to 1000 nits with hdr peak up to 1200 nits, contrast ratio is 2,000,000:1, and color is wide gamut p3 with true tone support and haptic touch. The cover glass is ion-exchange hardened with an oleophobic coating, and the touch layer is integrated for low latency input and stable edge response.
Connector layout matches the iPhone 13 Pro Max factory design for streamlined installation, with the notch cutout aligned for the truedepth system. The panel supports system-level features including night shift, hdr10 and dolby vision playback, and promotion frame pacing, preserving motion clarity for ui and media once calibrated in-system.
Compatibility, Pairing, And Shop Workflow
Fits model is iPhone 13 Pro Max and model id is A2643. The assembly is intended for device swaps, diagnostic rigs, and production repairs where an original panel is preferred. You should transfer or program display data to retain true tone, using your preferred screen programmer to copy the display serial the original panel and write it to the replacement.
Face id remains paired to the device’s original truedepth module and is not included with this display, so you should retain the customer’s paired module to preserve biometric functions. You should replace the perimeter adhesive during reassembly to help restore dust and moisture resistance, then run post-repair tests for touch grid, color uniformity, pwm flicker, 120 hz scrolling, and proximity behavior before final seal.
What You Receive And Grading
You receive iPhone 13 Pro Max - Black - Pulled Diagnostic Screen consisting of the oled panel, digitizer, and black front glass. Small parts such as brackets, gaskets, and frame adhesive are typically serviced from the original device as part of standard workflow and should be transferred or replaced as needed.
Pulled diagnostic screens originate from working units used for testing, so light handling marks on the frame or shield may be present and are not visible once installed. Each display is verified for accurate white point, consistent brightness across the panel, intact oleophobic coating, responsive touch on all axes, and stable promotion behavior, giving you an authentic look and feel that your customers expect from an original iPhone 13 Pro Max repair.
