iPhone 13 pro max jk incell display: fhd quality for reliable repairs
Built for busy benches, this fhd quality jk incell assembly for iphone 13 pro max (6.7 inch) delivers stable visuals and consistent touch at a price that makes sense for warranty work, insurance jobs, and high‑volume refurb. The incell stack integrates the digitizer into the lcd, trimming thickness and reducing flex points, so you get solid frame fit and fewer comebacks.
Resolution is 128 × 2778 with a fine sub‑pixel layout for crisp ui text and strong edge sharpness. Color tuning lands in a neutral range out of the box, with balanced gamma and a bright backlight for good indoor readability. The lens arrives with an oleophobic top coat and a cold‑pressed bezel, so you can seat it cleanly without shimming.
Key technical data and parts compatibility
• device: iphone 13 pro max only (models a2484, a2641, a2644, a2645, a2643).
• panel type: ltps ips lcd, incell touch layer.
• size and resolution: 6.7 inch, 1284 × 2778 px, full‑frame active area.
• refresh rate: 60 hz (no promotion).
• touch: 10‑point capacitive, fast gesture response.
• brightness and optics: high‑output backlight with wide‑angle polarizer and anti‑glare hardcoat on the lens.
• glass and frame: tempered cover glass, pre‑installed plastic/metal hybrid frame, speaker mesh fitted.
• included: display + touch assembly with bezel, camera/sensor bracket, dust mesh.
• not included: ear speaker + sensors flex (move from original), screws, waterproof adhesive.
Works with all current ios versions. face id remains intact when you transfer the original ear speaker/dot projector/sensor flex without damage. true tone can be restored by programming the original panel data into this unit using your preferred programmer before final seal.
Compared with oem oled, this lcd shows slightly warmer whites at default and smoother motion at 60 hz rather than 120 hz, which most shops accept for cost‑controlled repairs. Touch tracking is stable across corners and along the notch edge, with firm rejection of phantom inputs when the frame is fully seated.
Proximity and ambient light readings are consistent once the sensor window is aligned; take a moment to center the gasket to avoid screen‑off during calls or auto‑ drift. Face id performance is unchanged because authentication lives on the transferred flex, not the display.
Workshop tips for faster installation
Pre‑test on the table: connect battery, then display, and run a dead‑pixel, color bar, and 5‑point touch sweep before you close. Move the ear speaker assembly as a complete unit to avoid strain on the dot projector. If the old frame was bent, replace perimeter adhesive and clamp lightly after warm seating to maintain splash resistance.
For repeatable color, copy true tone data from the original screen, then reset auto‑brightness in settings. If you refurbish at scale, this panel bakes well with oca and fits standard lamination jigs thanks to uniform bezel dimensions. Every batch is qc‑checked for luminance uniformity, touch continuity, and line/spot defects so you can install with confidence.
